Variables Panel#

Variable is a container that holds some value. Depending on the type of variable, it can store numbers, text, tables, etc. The "Variables" panel in the Designer is intended for creating and deleting variables of the current diagram, as well as changing their type and initial value. In debug mode, this panel also shows the current value of each variable.

Variables are memory cells of the Robot, places for storing information necessary for its operation.

No.	Interface Element	Description
1.	button	Allows collapsing the "Variables" panel.
2.	button "Create"	Allows adding a new variable.
3.	button "Delete"	Allows deleting the selected variable.
4.	button	Allows copying the selected variable.
5.	button	Allows pasting the copied variable.
6.	button	Allows moving the selected variable up.
7.	button	Allows moving the selected variable down.
